Description

Lumen X Stadium Light: Defining the Future of LED Sports Lighting

The Lumen X Stadium Light is the next-generation solution for sports and industrial lighting, engineered for top-tier performance, flexibility, and longevity. Designed with modern venues in mind, Lumen X delivers unmatched light output, precision beam control, and simplified installation, making it the ideal choice for stadiums, sports complexes, large events, ports, and high-demand industrial sites.

High Performance with Flexibility

Choose from 600W, 700W, or 800W selectable wattage and enjoy consistent lumen efficacy of up to 160Lm/W, delivering up to 128,000 lumens. Engineered with high-performance Osram, Samsung, or Bridgelux LEDs, Lumen X ensures your lighting needs are met with brilliant, high-CRI output for visibility and color clarity.

Smart Controls and Compatibility

Lumen X Stadium Light supports DMX512, DALI, Zhaga, and 0-10V dimming, making it ideal for dynamic environments requiring advanced control systems. Easily integrated with modern building management systems or customized lighting solutions for events, sports broadcasts, or energy efficiency goals.

Designed for Retrofit and New Installations

The Lumen X is engineered to be a 1:1 replacement for traditional HID sports lighting systems, with compatibility for existing wiring and infrastructure. Perfect for new stadium builds or upgrading outdated lighting systems without the need for expensive rewiring.

Lightweight and Ergonomic Design

Weighing only 37.91 lbs (17.2kg), the Lumen X is 15%-20% lighter than comparable lights in the industry. The ergonomic design includes a comfortable silicone handle and self-locking screws that streamline installation, maintenance, and transport, reducing labor costs and time.

Modular Construction and Quick Maintenance

The innovative PowerBox serves both as a junction box and a driver housing, designed for fast, secure wiring. Its separable structure allows for swift on-site maintenance or upgrades, further reducing downtime and operational costs.

A knife switch ensures power is automatically cut when the power box is separated—enhancing worker safety during high-altitude maintenance.

Precision Beam Control

With multiple visor lengths and beam angle options (10°, 15°, 20°, 40°, 60°), the Lumen X allows for tailored light distribution. The adjustable visor dramatically reduces glare and spill while maximizing field illumination, making it ideal for high-performance sports lighting.

Superior Durability and Efficiency

• IP66 waterproof and IK10 impact resistance ratings ensure reliable performance in extreme environments.
• Advanced heat dissipation through high thermal conductivity aluminum and vented design
• Corrosion-resistant surface treatment suitable for coastal and industrial areas
• Operating temperature: -40°C to +50°C (-40°F to +122°F)

Long Life and Warranty

• Rated for 100,000 hours (L70B50) of operation
• Backed by a 7-year warranty (5-year for non-isolated models)

Compact Size for Reduced Freight and Storage

Dimensions start at 620x288x331mm (24.41×11.14×13.03 in) with packaging only 655x470x325mm, saving on shipping and storage costs. Ideal for distributors and wholesalers looking to optimize logistics.

Applications

• Stadiums & Sports Complexes
• Football and Soccer Fields
• Large Outdoor Events
• Industrial & Construction Sites
• Ports and Crane Lighting
• Parking Lots & Airports
• Security Lighting

Certifications & Components

• UL, DLC, CE, CB, ENEC, RoHS
• Premium drivers: uPowerTek, Powerland
• Die-cast aluminum housing, high-transmittance polycarbonate lens

Mounting Options

• U-Bracket
• Top Arm Mount (optional)
• Size-customized visor configurations

Choose the Lumen X Stadium Light for a lighting solution that combines cutting-edge technology, long-term reliability, and cost-saving features. Whether you’re lighting a brand-new stadium or upgrading an old facility, Lumen X is your smart investment in the future of sports and industrial lighting.
